China Massey Ferguson tractor hydraulic pump
Massey Ferguson Tractor Hydraulic Gear Pumps
China direct factory supplying direct-replacement hydraulic gear pumps for Massey Ferguson agricultural tractors (MF 135, 165, 240, 265, 390).
Source Factory
China Direct (2,800m² Plant)
Pressure Rating
Up to 25 MPa / 250 bar
DFM Analysis
< 24 Hours Turnaround
Testing Standard
100% Bench Tested
Product overview
Massey Ferguson Tractor Hydraulic Gear Pumps manufacturing starts with confirmed technical requirements.
Review machine application, displacement, working pressure, port threads, and rotation direction before requesting a quotation.
The two smallest entries are identified by manufactory reference rather than tractor model: MF #10 pump at 5.0 ml/r and 120 bar with NPT 3/8 and NPT 1/4 ports, and MF #9 pump at 6.0 ml/r and 120 bar with the same NPT ports. Both rotate clockwise. The MF 375 and MF 385 entries both use 6.2 ml/r with M18x1.5-6H ports on both feed and discharge and both rotate anti-clockwise, but they differ in pressure (175 bar against 160 bar) and speed rating (3000 r/min against 1500 r/min highest). That speed difference alone makes them non-interchangeable. The two mid-range entries at 14 ml/r and 20 ml/r are rated 250 bar and 200 bar with plain metric port diameters, and the largest 22 ml/r entry at 250 bar uses a G1 (BSP) feed and a 7/8-24UNF 2B discharge.
Rated PressureUp to 25 MPa (250 bar)
Max SpeedUp to 3,600 r/min
Quality Control100% Flow & Pressure Test
Massey Ferguson Tractor Hydraulic Gear PumpsFactory Genuine Spec
Selection guidance
How to specify a massey ferguson tractor hydraulic gear pumps for quotation.
Use equipment model, OEM reference numbers, rotation direction, and port threads to verify exact replacement compatibility.
1. Confirm the OEM reference number first. MASSEY FERGUSON tractors of the same model year can carry different pump part numbers depending on whether the machine has factory hydraulic remotes, a loader valve, or power steering priority. 2. Match displacement, not just the mounting flange. Nominal displacement in ml/r sets flow at a given engine speed. A larger displacement raises flow but also raises drive torque and heat load. 3. Confirm rotation direction. Catalogue entries are listed as Right (Clockwise) or Left (Anti-clockwise) as viewed from the drive end. A pump run backwards will not prime. 4. Check both port threads before ordering. The catalogue mixes UNF, metric fine (M18x1.5, M16x1.5, M14x1.5), BSP (G), and NPT threads within the same brand family. Adapters add leak points and cost. 5. Match pressure capability to the relief setting. Maximum pressure in the catalogue is the pump rating, not the system setting. The relief valve normally limits working pressure below that figure. 6. Check the controlled flow rate where listed. Some entries include a controlled flow rate in L/min, which matters for steering and constant-flow circuits.
Technical specifications
Core technical parameters for engineering and procurement review.
| Product type | Hydraulic gear pump |
|---|---|
| Entries in catalogue | 7 |
| Displacement range | 14 ml/r to 6.2 ml/r |
| Maximum pressure range | 120 bar to 250 bar |
| Speed range | 1500 r/min (highest) to 600-3000 r/min |
| Controlled flow rate | 5.0 L/min to 9.3 L/min |
| Port configurations | G1 / 7/8-24UNF 2B to Φ20 / Φ15 |
| Rotation directions available | Left (Anti-clockwise) to Right (Clockwise) |
| Material | Not published in catalogue |
| Standard | No product standard stated in catalogue |
| Custom options | Sample-based and drawing-based development accepted |
Catalogue Interchange Reference
Available Models & OEM Reference Specifications
Cross-check OEM part numbers, displacement, max pressure, port threads, and rotation direction before ordering.
| # | Applied To | Catalogue Page | OEM Ref. No. | Manufactory Ref. | Displacement | Max Pressure | Speed | Controlled Flow | Feed Port | Discharge Port | Rotation |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | MF Tractors | 9 | MF-HEMA | MF #10 pump | 5.0 ml/r | 120 bar | 3600 r/min (highest) | 5.0 L/min | NPT 3/8 | NPT 1/4 | Right (Clockwise) |
| 2 | MF Tractors | 9 | Not published | MF 375 | 6.2 ml/r | 175 bar | 3000 r/min (highest) | 9.3 L/min | M18*1.5-6H | M18*1.5-6H | Left (Anti-clockwise) |
| 3 | MF Tractors | 9 | 3533911M91, 3538958M91 | Not published | 14 ml/r | 250 bar | 500-3000 r/min | Not published | Φ19 | Φ14 | Left (Anti-clockwise) |
| 4 | MF Tractors | 9 | 7228132, 72277154, 2452995 | Not published | 20 ml/r | 200 bar | 600-3000 r/min | Not published | Φ20 | Φ15 | Right (Clockwise) |
| 5 | MF Tractors | 9 | 527904M93, 773126M92 | MF #9 pump | 6.0 ml/r | 120 bar | 500-3600 r/min | 6.0 L/min | NPT 3/8 | NPT 1/4 | Right (Clockwise) |
| 6 | MF Tractors | 9 | Not published | MF 385 | 6.2 ml/r | 160 bar | 1500 r/min (highest) | 9.3 L/min | M18*1.5-6H | M18*1.5-6H | Left (Anti-clockwise) |
| 7 | MF Tractors | 9 | 041682T1, 041683T2 | Not published | 22 ml/r | 250 bar | 250-2500 r/min | Not published | G1 | 7/8-24UNF 2B | Right (Clockwise) |
* Note: Cross-check OEM reference number, rotation direction, and port threads against the existing pump on your machine. All models can also be custom manufactured from samples or drawings.
Custom options
Manufacturing details that can be reviewed before quotation.
- Clockwise (CW) or Anti-Clockwise (CCW) rotation configurations
- Multiple port thread standards: UNF, metric fine, BSP (G), and NPT
- Splined, cylindrical keyed, or tapered drive shaft options
- Integrated priority flow control valves for steering circuits
- Custom development from buyer 2D/3D CAD drawings or physical samples
Quality control
Inspection points tied to the approved technical file.
- 100% computerized end-of-line bench testing for flow, pressure, and leakage
- Micro-inch CMM dimensional verification of mounting pilot and shaft journals
- Volumetric efficiency validated under full rated operating pressure
- Batch traceability and inspection certificate supplied with every order
All products can be custom manufactured from 2D/3D CAD drawings or physical samples.
Quality Control & Inspection Matrix
Engineering Evidence & 100% Inspection for Massey Ferguson Tractor Hydraulic Gear Pumps.
Overseas procurement teams require verifiable technical data, not unsupported claims. Every production batch at ZhongYi is inspected against approved CAD blueprints and international standards (DIN, AGMA, ISO).
Component-Specific Quality Focus:
The supplier holds an IATF 16949:2016 certificate (certificate number DB00992, IATF registration number 0454540, issued 26/07/2022, expiring 25/07/2025). IATF 16949 covers automotive-sector quality management system requirements; it is not a product type approval and does not by itself certify any individual pump model. The catalogue does not publish material grades, heat treatment specifications, volumetric efficiency test data, or endurance test results. Buyers who need those should request them directly rather than assume they exist: dimensional inspection reports for the mounting flange, shaft, and port threads; material certificates for the housing and gear set; volumetric and overall efficiency test curves at rated speed and pressure; sample pumps for fitment and bench testing before a production order; and confirmation of the drawing revision used for manufacture. Because the certificate expiry date has passed relative to many buying cycles, ask for the current certificate before qualifying the supplier.
Coordinate Metrology
Zeiss / Hexagon 3D CMM
Validates 3D spatial GD&T, bore concentricity, center distance, and geometric tolerances down to ±0.002 mm.
Tooth Geometry Analysis
Klingelnberg CNC Gear Analyzer
Inspects involute tooth profile error (fα), lead crowning (fβ), pitch cumulative error (Fp), and radial runout (Fr).
Hardness & Case Depth
Digital Micro-Vickers & Rockwell Testers
Verifies surface hardness (58–62 HRC), core toughness, and effective carburized / nitrided case depth gradient.
Chemical Metallurgy
Direct-Reading Optical Spectrometer
100% chemical composition verification of alloy steel forgings (20CrMnTi, 42CrMo, 18CrNiMo7-6, Stainless, POM).
Inspection Deliverables with Every Shipment
Complete Batch Traceability & Certified Test Reports
- EN 10204 Type 3.1 Mill Test Certificate (Chemical & Mechanical Properties)
- Zeiss 3D CMM Full Dimensional Inspection Sheet
- Klingelnberg Tooth Profile & Lead Crowning Graph Report
- Effective Carburized Case Depth & Hardness Curve Data
- 100% Pre-Shipment Visual, Thread & Anti-Rust Quality Verification
Our Factory Quality Commitment:
We maintain strict incoming material spectroscopy, in-process CNC tooth coordinate monitoring, and 100% final pre-shipment dimensional inspection. All custom gear batches are backed by our full manufacturing warranty.
ISO 9001:2015 Certified
DIN 4-7 / AGMA 11-13 Standards
Applications
Massey Ferguson Tractor Hydraulic Gear Pumps operating environments.
Confirm load, speed, duty cycle, environment, lubrication, and assembly constraints before selecting the final material and manufacturing route.
- Massey Ferguson tractor hydraulic systems and rear linkage
- Replacement supply for MF 375 and MF 385 machines
- Workshops servicing mixed Massey Ferguson fleets
- Markets where NPT-threaded hydraulic fittings are the local standard
Application Markets
View All 5 Industry Hubs →Where Massey Ferguson Tractor Hydraulic Gear Pumps Are Engineered & Deployed
Discover how this gear category meets extreme torque, low backlash, quiet operation, and weather-resistance demands in primary industry sectors:
🤖Sub-Arcminute Motion & Dynamic Positioning
Automation & Robotics
Low-backlash, ultra-precise fine-pitch gears, ground helical racks, and planetary gearheads for robotics, AGV wheel drives, and high-speed motion axes.
🌾Rugged Heavy-Torque Transmission
Agriculture & Farm Equipment
High-torque bevel gears, spur gears, and splined drive shafts for tractors, harvesters, rotary tillers, and agricultural PTO gearboxes.
Technical FAQ
Common questions before ordering massey ferguson tractor hydraulic gear pumps products.
Critical specifications are confirmed against final drawings before production.
Can I replace an MF 375 pump with an MF 385 pump?▼
Not on specifications alone. Both are 6.2 ml/r with M18x1.5-6H ports and anti-clockwise rotation, but the MF 375 is rated 3000 r/min highest while the MF 385 is rated 1500 r/min highest. Fitting the lower-rated pump to a faster drive will overspeed it.
